Name: 40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-QSFP-40G-LX4
Price: 81.00 USD
Availability: InStock

Thuis > producten > QSFP+ zendontvanger >

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

1270~1330nm QSFP+ Transceiver

4 CWDM Lanes MUX/DEMUX Optical Module

2km Fiber Optic Transceiver

Plaats van herkomst:

Guangdong, China

Merknaam:

HILINK

Certificering:

CE FCC Rohs

Modelnummer:

HL-QSFP-40G-LX4

Neem contact met ons op

Vraag een offerte

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Productgegevens

Productennaam:

40G QSFP+ 2 km

Connetor:

Duplex LC

Gegevenssnelheid:

40 g

Afstand:

2 km

Temperatuurbereik:

0°C ~ +70°C

Certificering:

RoHS Compliant

Type:

Glasvezel zendontvangers, 40 g QSFP+

Digitale diagnostische functies:

Ingebouwd

Betaling en verzendvoorwaarden

Min. bestelaantal

1 stks

Prijs

EXW: 75~87USD/PCS

Verpakking Details

De statische zak, Plastic Vlakke, Kleinhandelsdoos, vereist langs

Levertijd

5-8workingdays

Betalingscondities

Western Union, T/T, L/C

Levering vermogen

100 stcs/maand

Verwante producten

40G QSFP+ SWDM4 Optical Transceiver with 240m/350m Distance Duplex LC Connector and Built-in Digital Diagnostics

Krijg Beste Prijs

40Gb/s 150m QSFP+ SR4 Transceiver Glasvezel Optische Module MPO Connector

Krijg Beste Prijs

40Gb/s 100m QSFP+ Glasvezel Optische Module Bi-Di Duplex LC Hot Pluggable 850/900nm MMF

Krijg Beste Prijs

40Gb/s 60km QSFP+ Transceiver Hot Pluggable Duplex LC Connector Single mode

Krijg Beste Prijs

Neem contact met ons op

86-755-8317-6243

Contact opnemen

Productbeschrijving

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Product Description

40Gb/s LX4 IR4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Key Features

Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
Duplex LC connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-SR4/IR4 Standard
QSFP MSA compliant
Maximum link length of 100m on OM3 and 150m on OM4
4 CWDM lanes MUX/DEMUX design
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Operating temperature range: 0°C to 70°C
RoHS Compliant

Applications

Rack to rack connections
Data center switches and routers
Metro networks
40G Ethernet links

Technical Details

The HL-QSFP-40G-LX4 transceiver module is designed for 2km (SMF) and 150m (MMF) optical communication applications. Compliant with 40GBASE-SR4 and 40GBASE-LX4 of the IEEE P802.3ba standard, it converts 4 input channels of 10Gb/s electrical data to 4 CWDM optical signals, multiplexing them into a single channel for 40Gb/s optical transmission. On the receiver side, it optically de-multiplexes a 40Gb/s input into 4 CWDM channel signals and converts them to 4 channel output electrical data.

Our Services

We offer OEM and ODM services for custom orders.

Quality Guarantee

All optical transceivers are brand new with new components, never using old or refurbished materials. Each unit undergoes functional and aging tests. We provide a 3-year warranty from the date of shipment.

Product Range

We supply compatible optical transceiver modules including SFP, GBIC, SFP+, XENPAK, X2, XFP, BIDI, CWDM, DWDM and other special modules compatible with most major brands.

Packaging & Shipping

We ship internationally via DHL, FedEx, EMS, TNT, UPS with delivery in 3-7 days.
